Material | Commonly: Q345B/A572, Q235B/A36, Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, ST52 |
||||
Height | 15M | 20M | 25M | 30M | 40M |
Dimensions (d/D) | 120mm/ 280mm | 220mm/ 460mm | 240mm/ 520mm | 300mm/ 600mm | 300mm/ 700mm |
Thickness | 5mm+6mm | 6mm+8mm | 6mm+8mm+10mm | 8mm+8mm+10mm | 6mm+8mm+10mm+12mm |
LED Power | 400W | 600W | 700W | 800W | 1000W |
Color | Customized | ||||
Surface treatment | Hot-dip Galvanized and Electrostatic Spraying, Rust Proof, Anti-corrosion performance Class II | ||||
Shape Type | Conical pole, Octagonal pole | ||||
Stiffener | With big size to strength the pole to resist the wind | ||||
Powder coating | Thickness of powder coating>100um. Pure polyester plastic powder coating is stable, and with strong adhesion & strong ultraviolet ray resistance. Film thickness is more than 100 um and with strong adhesion. The surface is not peeling even with blade scratch (15×6 mm square). |
||||
Wind Resistance | According to local weather condition, General design strength of wind resistance is ≥150KM/H | ||||
Welding Standard | No crack, no leakage welding, no bite edge, weld smooth level off without the concavo-convex fluctuation or any welding defects. | ||||
Hot-Dip Galvanized | Thickness of hot-galvanized>80um. Hot Dip Inside and outside surface anti-corrosion treatment by hot dipping acid. which is in accord with BS EN ISO1461 or GB/T13912-92 standard. Designed life of pole is more than 25 years, and the galvanized surface is smooth and with the same color. Flake peeling hasn’t been seen after maul test. |
||||
Lifting device | Ladder climbing or electric | ||||
Anchor bolts | Optional | ||||
Material | Aluminium,SS304 is available | ||||
Passivation | Available |
Tianxiang Light Is One Of The World’s Most Trusted Lighting Brands.
Tianxiang Light Occupies Workshop Space Of 4500 m², Now We Have More Than 200 People,Especially 3 in R & D Department, 5 in QC Department,8 Engineers.So Far We
Have Over 10 Patent Technologies. The Tianxiang Lamp Series And Solar Powered Lamps Have Been Widely Used In The Industry. Our Facilities Are Certified With ISO9001,
SGS, TUV, And Our Products Comply With CE, ROHS, IEC,SONCAP etc.
1. Q: Are you a factory or trading company?
A: We are factory established for 12 years, specialized in outdoor lights.
2. Q: Where is your factory located? How can I visit there?
A: Our factory is located in Yangzhou City, Jiangsu Province, China, about 2 hours drive from Shanghai. All our clients, from home or abroad, are warmly welcome to visit us!
3. Q: What’s your main product?
A: Our main product is Solar Street Light, LED Street Light, Garden Light, LED Flood Light, Light Pole And All Outdoor Lighting
4. Q: Can I try a sample?
A: Yes. Samples for testing quality is available.
5. Q: How long is your lead time?
A: 5-7 working days for samples; around 15 working days for bulk order.
6. Q: What’s your shipping way?
A: By air or sea ship are available.
7. Q: How long is your warranty?
A: 5 years for outdoor lights.
Focus on providing mong pu solutions for 5 years.
